HKFR Series quick-disconnect, hydraulic coupling for hazardous BOP (Blow-out Preventer) service
Hansen HKFR series BOP safety couplings BOP快速接头
HKFR Series HKFR系列防火型快速接头

Hansen HKFR系列防火 消防安全接头被设计用于危险领域，该系列产品通过并达到API及加拿大EUB的标准，可以在燃烧现场继续维持一段时间，最高耐温700℃，在石油平台的封井器BOP上有广泛的应用。

该防火型快速接头是设计用于火灾情形下使用的。它的性能要求超过API 16D 和EUB Directive 36。规格从1/2”到1”的HKFR 系列快速接头，其材质为钢，1”的快速接头有AISI 303 不锈钢材质。所有规格的快速接头都具有单独的Lloyd’s 登记证书。它采用便于连接及断开的球锁机构，是防喷装置的理想选择。它紧凑的设计适用于空间有限的金属建筑嵌板。该设计被用于工作压力为200 和275 bar/3,000 和4,000psi 的场合。它含有BOP 标记和红色的编码，帮助视觉识别。

HKFR Series quick-disconnect, hydraulic coupling for hazardous BOP (Blow-out Preventer) service
Hansen HKFR series BOP safety couplings BOP快速接头

The Fire-Rated Coupling is a quick coupling designed to operate under emergency fire conditions. It exceeds all requirements of API 16D and EUB Directive 36. HKFR Series is available from 1/2” to 1” in steel and in AISI 303 stainless steel for size 1”. All sizes have individual Lloyd’s Register Certification. Easy to connect / disconnect thanks to its ball lock mechanism, this coupling is ideal for Blow-Out Preventer applications and for building panels where space is limited thanks to its compact design. This series is designed for applications with 200 & 275 bar / 3,000 & 4,000 psi working pressures. It presents BOP marking and red color coding to help visual identification.

Hansen HKFR系列防火/消防安全接头被设计用于危险领域，该系列产品通过并达到API及加拿大EUB的标准，可以在燃烧现场继续维持一段时间，最高耐温700℃，在石油平台的封井器（BOP）上有广泛的应用。 HKFR Series is a quick-disconnect, hydraulic coupling designed for hazardous BOP (Blow-out Preventer) service in the oil and gas industry. It meets or exceeds the ISO7241-1 Series B standard.

产品特性：

1、 达到并超过API 16D和EUB 36的标准
2、 通过劳氏船级社认证
3、 可在最高温度700℃场合下工作
4、 口径 3/4”、1/2”和1”
5、 红色套筒标识，清晰明了
6、 标配套筒锁防止误操作
7、 适用于石油平台，狭窄的场合
8、 是世界上第一款专为封井器（BOP）设计的快速接头

HKFR Series: Enhanced Design for BOP (Blow-out Preventer) Service

Eaton’s HKFR Series is a quick disconnect, hydraulic coupling, that is designed for hazard-ous BOP (Blow-Out Preventer) service in the Oil & Gas Industry. It meets or exceeds the ISO 7241-1 Series B standard.

Part Number 4HFR26 4KFR26 Part Number 6HFR31 6KFR31
Part Number 8HFR36 8KFR36 Part Number ML8HFR36 ML8KFR36
4HFR26 / 4KFR26: 3,000 PSI / 206 BAR
6HFR31 / 6KFR31: 3,000 PSI / 206 BAR
8HFR36 / 8KFR36: 4,000 PSI / 275 BAR
ML8HFR36 / ML8KFR36: 4,000 PSI / 275 BAR

伊顿现在为BOP防喷器应用提供 Hansen 防火 (HKFR) 液压快速接头
Eaton Now Offers Hansen Fire-Rated (HKFR) Quick-Disconnect Hydraulic Couplings For Blow-Out Preventer Applications
Date: March 22, 2011

明尼苏达州。…多元化的工业制造商伊顿公司今天宣布推出 HKFR 系列防火液压快速接头，用于石油和天然气防喷器 (BOP) 的高温、安全相关应用。HKFR 系列是伊顿于 2010 年 12 月被伊顿收购的 Hansen? 和 Coupleurs Gromelle? 产品系列的一部分。

伊顿的 HKFR 系列联轴器符合 ISO 7241-1 B 系列标准，并具有符合 API 16D 和 EUB 指令 35 规定条件的劳氏船级社证书。

“HKFR 系列联轴器设计用于石油和天然气行业的危险防喷器服务，”伊顿联轴器业务总监 Brett Jaffe 说。“插座和插头均标有‘BOP’，套筒套筒和扳手平面为红色，便于安装后目视识别。其可靠的球锁机构无需工具即可快速连接和断开，因此不存在交叉螺纹风险，标准套筒锁可防止意外断开。”

伊顿 HKFR 系列接头采用双通阀设计，可最大限度地减少流体溢出，结构非常紧凑，非常适合空间有限的面板。它们有四种阀体尺寸可供选择：?”，工作压力为 7,000 psi (482 bar)，爆破压力为 28,000 psi (1,931 bar)；和 ?” 和 1.0”，工作压力为 5,000 psi (344 bar)，爆破压力为 20,000 psi (1,379 bar)。1.0” 接头采用不锈钢材质。

自 1915 年 Fred Hansen 开发出第一款快速断开接头以来，Hansen 接头一直是技术领导者。作为伊顿液压集团的一部分，Hansen 和 Coupleurs Gromelle 的产品、技术、工程和制造能力显着增强了伊顿满足各种液压和气动市场需求的能力。

EDEN PRAIRIE, Minn. …Diversified industrial manufacturer Eaton Corporation today announced the availability of the HKFR-Series of fire-rated quick-disconnect hydraulic couplings for high-temperature, safety-related applications on oil and gas blow-out preventers (BOP). The HKFR-Series is part of Eaton’s line of Hansen? and Coupleurs Gromelle? products which were acquired by Eaton in December, 2010.

Eaton’s HKFR-Series couplings meet the ISO 7241-1 Series B standard and carry a Lloyd’s Registry Certificate for the conditions stated in API 16D and EUB Directive 35.

“HKFR-Series couplings are engineered to perform in hazardous BOP service in the oil and gas industry,” said Brett Jaffe, couplings business director, Eaton. “Both the socket and plug are marked ‘BOP’ and the socket sleeve and wrench flats are red, all for easy visual identification after installation. Their dependable ball-locking mechanism connects and disconnects quickly without tools, so there is no risk of cross threading, and the standard sleeve lock prevents accidental disconnection.”

Eaton HKFR-Series couplings feature a two-way valve design that minimizes fluid spillage, and a very compact configuration that fits well into panels with limited space. They are available in four body sizes: ?” with a 7,000 psi (482 bar) working pressure and 28,000 psi (1,931 bar) burst pressure; and ?”, and 1.0” with a 5,000 psi (344 bar) working pressure and 20,000 psi (1,379 bar) burst pressure. The 1.0” couplings are available in stainless steel.

Hansen couplings have been technology leaders since 1915 when Fred Hansen developed the first quick-disconnect coupling. As part of Eaton’s Hydraulics Group the products, technology, engineering, and manufacturing capabilities of Hansen and Coupleurs Gromelle significantly enhance Eaton’s ability to serve diverse hydraulic and pneumatic market needs.
