适用于铁路应用的防紫外线和阻燃型Ty-Rap?电缆扎带
UV-resistant and flame retardant Ty-Rap. cable ties for the railway industry
用于铁路行业应用的新型Ty-Rap电缆扎带
Ty-Rap Cable ties for the railway industry


现代铁路车辆的要求不仅苛刻而且还时时发生变化。恶劣的安装条件、环境条件以及日益严格的(旅客)安全需求都要求使用具有出色性能的电缆扎带。


为此,ABB特别开发了适用于铁路行业(RW)的Ty-Rap电缆扎带,满足现代铁路车辆应用需求。MX-RW电缆扎带具有符合ISO 4892-2标准的防紫外线保护功能,适合户外应用;通过了IEC / EN 62275、UL 1565、EN 45545 HL2 (R22和R23)以及法国NF F 16-101 / -102 I3 / F2测试,适用于具有特殊防火需求的场所,例如客车。


新型Ty-Rap铁路应用电缆扎带长度92 mm至360 mm,宽度2.4 mm至 7.0 mm,适用的电缆直径最大为100 mm。2种扎带都采用尼龙6.6制造,其材料是有机硅,不含卤,可耐受温度为-40 ° C至+ 85 °C。此外,ABB还专门研发了符合人体工学的新型工具,帮助工作人员高效安装电缆扎带。


- 符合NFF 16-101标准(法国铁路组件防火测试标准)
- 符合EN 45545-2(铁路应用-铁路车辆防火-第二部分:材料及组件防火要求)
- 高端电缆扎带(通过钢锁倒钩保护并管理电缆)
- Grip of Steel:船用级非磁性316不锈钢倒钩
- 圆边,防止锋利边缘损坏电缆
- 光滑无痕,电缆扎带更牢固
- 扎带表面的楞纹和颗粒可防止扎带受到震动和外部冲击时滑落
- 防紫外线和阻燃Ty-Rap?电缆扎带符合最新标准
- 完整系列Ty-Rap?电缆扎带提供多种尺寸可供选择,抗拉强度最高达到540 N



- 下载与链接




Ty-Rap Cable ties for the railway industry
UV-resistant and flame retardant Ty-Rap. cable ties for the railway industry

- Premium cable ties with steel locking barb to secure and manage cables
- The “Grip of Steel” Non-Magnetic Stainless Steel locking Barb – marine grade type 316
- Rounded edges to prevent sharp edges from damaging cables
- Smooth, notchless body, making the cable ties stronger
- Ribbed and Stippled surface to prevent the tie from slipping under vibration conditions and external shock
- UV-resistant and flame retardant Ty-Rap. cable ties are certified to the latest standard for the train industry
- Tested according to the NFF 16-101 standard
- Tested according to the EN 45545-2
- Complete range of Ty-Rap. cable ties in different dimensions up to a tensile strength of 540N



Product Length Width Thick-Bundle Minimum Quantity Product

TY23MX-RW
TY23MFR-RW
TY232MX-RW
TY232MFR-RW
TY234MX-RW
TY24MFR-RW
TY24MX-RW
TY25MFR-RW
TY242MX-RW
TY28MFR-RW
TY26MX-RW
TY27MFR-RW
TY244MX-RW
TY25MX-RW
Dedicated Tooling: ERG-50 and ERG-120
TY253MX-RW
TY28MX-RW
A comprehensive range of tensio
TY271MX-RW
500 ning and cutting tools are available:
TY272MX-RW
500 - Economy tools for low volumes
TY27MX-RW
-Semi-automatic hand tools for
Technical information UV-resistant cable ties

Material – Moulding
Polyamide 6.6

Material – Locking barb
316 grade stainless steel

Temperature range
-40°C to +85°C

Colour
Black

Flammability rating
UL 94 V-2

Other properties
UV-resistant, Halogen free,
Silicon free

Test Result NFF 16-101
I3F2

Test Result EN 45545-2
HL2 for R22 and R23
requirement

Technical information Flame Retardant cable ties

Material – Moulding Polyamide 6.6
Material – Locking barb 316 grade stainless steel
Temperature range -40°C to +85°C
Colour White
Flammability rating UL 94 V-0
Other properties Halogen free, Silicon free
Test Result NFF 16-101 I3F1
Test Result EN 45545-2 HL3 for R22 and R23
