UHP PFA气动隔膜阀（1英寸）2通阀– PV-12系列
Parker PFA阀 - Parker PFA Valves
UHP PFA Air-operated Diaphragm (1 inch) 2 Way Valve – PV-12 Series

PV-12系列PFA隔膜阀具有很高的泄漏完整性和出色的耐腐蚀性。它非常适合用于超高纯度UHP和腐蚀性流体应用。提供2通和3通配置。PV-12系列是一种1英寸PFA气动隔膜阀，设计用于超高纯度（UHP）以及腐蚀性气体和液体处理系统，包括那些在半导体制造操作中使用的系统。该阀有2通和3通配置。三向配置具有多位置安装基座，可提供更大的安装灵活性并减少连接器装配，在可工作空间有限的区域中具有优势。

PV-12系列具有模制的PFA阀体，并具有精密加工的密封区域。它采用了含氟聚合物涂层的不锈钢弹簧，可减少腐蚀性环境的影响，并确保与各种腐蚀性工艺介质的兼容性。该阀还配备了一件式改良PTFE隔膜，与传统的PTFE相比，具有更长的循环寿命。根据客户要求，PV-12系列阀门可以装配多种口径配置，包括Parflare和Parbond管件。Parflare和Parbond配件都减少了组装时间和安装成本，同时确保了密封性，以确保清洁度至关重要的应用中的可靠性。

PV-12系列阀门的榫槽密封确保了膜片与阀体之间的可靠密封，从而实现了出色的泄漏完整性，较低的更换成本以及过程介质与执行器的隔离。该系列的全1英寸节流孔在紧凑的包装中提供了最大的流量能力（带Parbond的PV-12最高为15.7 Cv）。流量由配置和终端类型决定。该阀的双向额定压力为100 psig，驱动压力范围为60 – 100 psig。

PV-12系列具有潜水选项，可将组件与外部环境隔离，并允许阀门在潮湿或气体腐蚀性环境中运行时保持功能。

UHP PFA Air-operated Diaphragm (1 inch) 2 Way Valve – PV-12 Series

The PV-12 Series PFA Diaphragm Valve offers high leak integrity and exceptional corrosion resistance. It is ideally suited for use in ultra-high purity (UHP) and aggressive fluid applications. Available in 2-way and 3-way configurations.

The PV-12 Series is a 1 inch PFA air-operated diaphragm valve that is designed for use in ultra-high purity (UHP) and aggressive gas and liquid handling systems, including those used in semiconductor manufacturing operations. The valve is available in 2-way and 3-way configurations. The 3-way configurations have a multi-position mounting base, which allows for more mounting flexibility and connector fitting reduction, making the advantageous in areas where workable space is limited.

The PV-12 Series features a molded PFA body with precision-machined sealing areas. It utilizes a Fluoropolymer-coated stainless steel spring, which reduces the effects of corrosive environments and ensures compatibility with a wide range of aggressive process media. The valve is also equipped with a one-piece modified PTFE diaphragm, which provides higher cycle life when compared to conventional PTFE. Depending on customer requirements, the PV-12 Series valve can be fitted with a variety of port configurations, including Parflare and Parbond tube fittings. Both Parflare and Parbond fittings reduce assembly time and installation costs, while ensuring a leak-tight seal for reliability in applications where cleanliness is critical.

The tongue and groove seal of PV-12 Series valves ensures a positive diaphragm to body seal, resulting in superior leak integrity, lower replacement costs, and isolation of process media from the actuator. The series' full 1 inch orifice offers maximum flow capability in a compact package (up to 15.7 C?v for PV-12 with Parbond). Flow capacities are dictated by configuration and end type. The valve is bidirectionally pressure rated at 100 psig and has an actuation pressure range from 60 – 100 psig.

The PV-12 Series is available with a submergible option, which isolates components from the external environment and allows the valve to remain functional while operating in wet or gaseous corrosive environments.

市场：
- 半导体
- 分析实验室
- 制药
- BioPharm
- 航空航天
- 工业

功能/优点：
- 出色的泄漏完整性
- 改性的PTFE膜片和含氟聚合物涂层的不锈钢弹簧可提供较高的循环寿命并具有出色的耐腐蚀性
- 配备Viton?氟弹性体密封件
- 2通或3通方式配置
- 可以装配各种口径配置，包括Parflare和Parbond管配件
- 驱动压力范围：60至100 psig
- 完整的1英寸孔在紧凑的包装中提供了最大的流量
- 双向额定压力高达100 psig
- 环境温度范围：0°F至+ 150°F（-17°C至+ 66°C）
- 流体温度范围：0°F到+ 266°F（-17°C到+ 130°C）

应用：
- 腐蚀性和特种气体
- 半导体工具
- 工具连接件
- 阀箱（VMB）

Markets:
- Semiconductor
- Analytical Laboratory
- Pharmaceutical
- BioPharm
- Aerospace
- Industrial

Features/Benefits:
- Excellent leak integrity
- Modified PTFE diaphragm and Fluoropolymer-coated stainless steel spring provide high cycle life and exceptional resistance to corrosion
- Equipped with Viton? Fluoroelastomer seals
- Available in 2-way or 3-way configuration
- Can be fitted with a variety of port configurations, including Parflare and Parbond tube fittings
- Actuation pressure range: 60 to 100 psig
- Full 1 inch orifice provides maximum flow capability in a compact package
- Bidirectionally pressure rated up to 100 psig
- Ambient temperature range: 0°F to +150° F (-17°C to +66° C)
- Fluid temperature range: 0°F to +266° F (-17°C to +130° C)

Applications:
- Corrosive and specialty gases
- Semiconductor Tools
- Tool Hook-ups
- Valve Manifold Boxes (VMBs)

Technical Specifications

UHP PFA Air-operated Diaphragm (1 inch) 2 Way Valve – PV-12 Series 型号
