泄放阀，高压 - MPBV 系列 | #9HM-MPBV-V-SS
Bleed Valves, High Pressure - MPBV series | #9HM-MPBV-V-SS
Parker 仪表阀 - Parker Instrumentation Valves - MPBV series Bleed Valves, High Pressure

MPBV 系列泄放阀设计用于将系统的管线压力排放到大气或单独的密封管线。Parker 的 MPBV 系列排放阀设计用于高达 30,000 PSI 的高压系统。这些紧凑型排放阀用于其他阀门或系统，例如多阀歧管或仪表/根阀。独特的功能之一是，当与排放端口一起使用时，该排放阀可以将系统管线压力排放到大气或单独的密封管线。这为安装者提供了更灵活的应用程序。每当从系统中移除仪器或协助校准控制设备时，都会使用派克高压排放阀。

Parker's MPBV Series Bleed Valves

市场：

- 电力
- 化工/石化
- 纸浆和造纸
- 海上

特性/优势：

- 提供 316 不锈钢材质
- 排气口可用于引导系统管路中的多余气体或液体
- 紧凑型设计
- T 形杆手柄，无需扳手驱动
- 可选密封材料可用

应用：
- 多阀歧管
- 压力罐
- 校准系统
- 液压系统

Parker's MPBV Series Bleed Valves are designed to vent a system's line pressure either to atmosphere or a separate containment line. These compact bleed valves are rated to pressures up to 30,000 PSI.

Parker's MPBV Series Bleed Valves are designed for high pressure systems up to 30,000 PSI .These compact bleed valves are used on other valves or systems such as multi-valve manifolds or gauge/root valves. One of the unique features is that this bleed valve can vent the system line pressure to atmosphere or to a separate containment line when used with the vent port. This provides for a more flexible application for the installer. Parker high pressure bleed valves are used whenever an instrument is removed from a system or to assist in the calibration of control devices.

Markets:

- Power
- Chemical/Petrochemical
- Pulp and Paper
- Offshore

Features/Benefits:

- Available in 316 Stainless Steel
- Vent port available to direct excess gas or liquid from system lines
- Compact design
- T-bar handle for wrench-less actuation
- Optional seal material available


Applications:
- Multi-Valve Manifolds
- Pressure Tanks
- Calibration Systems
- Hydraulic Systems

技术规格

Technical Specifications

Bleed Valves, High Pressure - MPBV series 型号
