Hose Fittings
High Pressure Plugs
High pressure plugs are designed to be used with Polyflex high pressure fittings.
![](pic/Hose%20Fittings_130.jpg)
High pressure plugs are designed to be used with Polyflex high pressure fittings.
Markets:
- Hydraulics
- Industrial
- Oil & Gas
Features:
- Keeps contaminants/dust from getting into the connection opens
- Protects connection ends from damage
- Easy to put on and remove
![](pic/Hose%20Fittings_132.jpg)
![](pic/Hose%20Fittings_131.jpg)
![](pic/Hose%20Fittings_133.jpg)
![](pic/Hose%20Fittings_134.jpg)
![](pic/Hose%20Fittings_135.jpg)
![](pic/Hose%20Fittings_136.jpg)
Technical Specifications
Overall Length: |
Varies, Varies |
Shape: |
Straight |
Application: |
Oilfield, Marine |
Connection Type: |
Field-Attachable |
Hose Inside Diameter: |
1/16, 1/8, 1/4, 3/8, 1/2, 9/16, 5/8, 3/4, 1 inch, 1, 3, 6, 10, 13, 14, 16, 19, 25 mm |
Maximum Operating Pressure: |
4140 bar, 414 MPa, 60,000 psi |
Hex Size: |
0.5, 0.625, 0.812, 0.937, 1.375, 0.69, 1, 1.25, 1.5, 1.125, 0.375 inch, 12.7, 15.88, 20.62, 23.8, 34.93, 17.53, 25.4, 31.75, 38.1, 28.58, 9.53 mm |
Tube Outside Diameter: |
1/4, 3/8, 9/16, 3/4, 1 inch |
Materials of Construction: |
Stainless Steel |
High Pressure Plugs 型号
|
