Parker Fittings接头 - Compression Fittings
Transmission Fittings, Push-to-Connect



派克的推入连接式变速箱配件旨在减少组装时间，是压力保护型气动变速箱应用的理想选择。变速箱配件是压力保护气动变速箱应用的理想选择。推连接式变速箱配件减少了组装时间。推入连接式管支架具有一定的优势，并已通过DOT认证。化学镀镍体可与生物柴油一起使用。使用带有传动装置配件的SAE J844 A和B型尼龙管。Parker's Transmission fittings, push-to-connect style are designed to reduce assembly time and are ideal for pressure protected pneumatic transmission applications. Transmission fittings are ideal for pressure protected pneumatic transmission applications. Push-to-Connect style transmission fittings reduce assembly time. The push-to-connect style has a staked in tube support and is D.O.T. approved. Electroless nickel plated bodies can be used with bio-diesel. Use SAE J844 Type A & B nylon tubing with transmission fittings.



Transmission Fittings, Push-to-Connect



Markets:
- Heavy duty truck

Features/Benefits:
- All brass construction
- D.O.T. approved with staked in tube support
- Compression & Push-to-Connect styles
- Slotted sleeve
- Use with J844 nylon tubing
- Electroless nickel plated bodies can be used with bio-diesel

Applications:
- Air shift transmissions
- Seat controls
- Dash controls

市场：
- 重型卡车

特点/优点：
- 所有黄铜结构
- DOT认证，带衬管支撑
- 压缩和推入连接样式
- 开槽套筒
- 与J844尼龙管一起使用
- 化学镀镍主体可与生物一起使用柴油

应用：
- 空气变速箱
- 座椅控制装置
- 破折号控件

Technical Specifications

Connection Type: Push-to-Connect, Plug-In
Shape: 90° Elbow, Branch Tee,. Connector, Run Tee, Union and Tee
Minimum Operating Temperature: -40 °F, -40 °C
Maximum Operating Temperature: 220 °F, 104 °C
Maximum Operating Pressure: 150 psi, 10 bar
Tube Material: SAE J844 Type A & B Nylon Tubing
Application: Air Shift Transmission, Seat Controls, Dash Controls
Materials of Construction: Brass
Collet Material: Brass
O-Ring Material: Nitrile
Connection 1 Size: Push-to-Connect



Transmission Fittings, Push-to-Connect型号

Part Style Shape Connection 1 Tube O.D. (inch) Connection 2 Tube O.D. (inch) Connection 2 Thread Size (inch) Connection 2 Style
164PTC-3 Tube to tube Tee 3/16 3/16 na Push-to-Connect
164PTC-5/32 Tube to tube Tee 5/32 5/32 na Push-to-Connect
165PTC-3 Tube to tube 90° Elbow 3/16 3/16 na Push-to-Connect
165PTC-5/32 Tube to tube 90° Elbow 5/32 5/32 na Push-to-Connect
169PTCNS-12-8 Tube to Pipe 90° Elbow 3/4 na 1/2 Male Pipe
169PTCNS-3-2 Tube to Pipe 90° Elbow 3/16 na 1/8 Male Pipe
169PTCNS-3-4 Tube to Pipe 90° Elbow 3/16 na 1/4 Male Pipe
169PTCNS-5/32-1 Tube to Pipe 90° Elbow 5/32 na 1/16 Male Pipe
169PTCNS-5/32-2 Tube to Pipe 90° Elbow 5/32 na 1/8 Male Pipe
169PTCNS-5/32-4 Tube to Pipe 90° Elbow 5/32 na 1/4 Male Pipe
171PTCNS-3-2 Tube to Pipe Run Tee 3/16 na 1/8 Male Pipe
171PTCNS-5/32-2 Tube to Pipe Run Tee 5/32 na 1/8 Male Pipe
171PTCNS-5/32-4 Tube to Pipe Run Tee 5/32 na 1/4 Male Pipe
172PTCNS-3-2 Tube to Pipe Branch Tee 3/16 na 1/8 Male Pipe
172PTCNS-5/32-2 Tube to Pipe Branch Tee 5/32 na 1/8 Male Pipe
172PTCNS-5/32-4 Tube to Pipe Branch Tee 5/32 na 1/4 Male Pipe
62PTC-3 Tube to tube Union 3/16 3/16 na Push-to-Connect
62PTC-5/32 Tube to tube Union 5/32 5/32 na Push-to-Connect
66PTC-3-2 Tube to Female Pipe Connector 3/16 na 1/8 Female Pipe
66PTC-5/32-2 Tube to Female Pipe Connector 5/32 na 1/8 Female Pipe
66PTC-5/32-4 Tube to Female Pipe Connector 5/32 na 1/4 Female Pipe
68PTC-3-1 Tube to Pipe Connector 3/16 na 1/16 Male Pipe
68PTC-3-2 Tube to Pipe Connector 3/16 na 1/8 Male Pipe
68PTC-3-4 Tube to Pipe Connector 3/16 na 1/4 Male Pipe
68PTC-5/32-1 Tube to Pipe Connector 5/32 na 1/16 Male Pipe
68PTC-5/32-2 Tube to Pipe Connector 5/32 na 1/8 Male Pipe
68PTC-5/32-4 Tube to Pipe Connector 5/32 na 1/4 Male Pipe
