Parker派克2通软阀座海底球阀
Parker 2-Way Soft Seat Subsea Ball valve

Parker派克2通海底球阀具有软阀座和浮球设计,可用于高达10,000 PSI的工作深度和3050m的深度。根据API 17D PSL 3(包括API 6A PR2F)进行设计和测试,以在海底应用中提供安全可靠的性能。派克的软座直角回转球阀用于流量隔离,专门设计用于在海底应用中提供平稳,低扭矩的性能。利用与标准Parker的Hi-Pro系列球阀相同的设计技术,海底设计结合了必要的设计变更,可为海底行业提供可靠的外部加压阀。这种海底球阀设计采用PEEK自卸式阀座和PTFE填料,具有附加的O形圈密封,可防止海水进入阀门,这会对阀门的操作产生不利影响并污染工艺液体。双向阀提供多种耐腐蚀合金,适用于深度达3,050m的设备。阀门的设计便于手动操作或通过遥控车ROV进行操作。派克的海底球阀经过设计,可以达到或超过API 17D PSL 3的严格资格测试要求。结构完整性和性能已通过劳埃德检验员在见证API 17D阀门设计验证协议的情况下得到确认。这是在316SS模型的基础上进行的,包括API 6A PR2F PSL3双向测试协议以及API 17D高压测试协议。

Parker派克2通软阀座海底球阀
Parker 2-Way Soft Seat Subsea Ball valve
Small Bore Subsea Valves Transforming Offshore Oil and Gas Exploration

市场:
- 上游石油和天然气(液体介质)

特性/优点:
- 两件式浮球式侧面入口结构
- 双向液体流
- PEEK阀座具有出色的耐化学性,耐热性和耐磨性
- 畅通的10mm流路
- 低摩擦,压力辅助的PTFE轴密封延长使用寿命,降低操作扭矩
- 额外的密封设计,可防止水和淤泥渗入任何螺纹或旋转的部件
- 设计用于接受多种类型的管和管端连接
- 提供多种耐腐蚀材料
- 经过设计和测试,可API 17D / API 6A标准

应用(液体介质):
- 水下液压歧管
- 水下控制脐带
- 水下井口和控制组件
- 化学注入
- DBB,排放,通风口,测试线。





Subsea Ball valve, 2-Way, Soft Seat

Parker 2-way subsea ball valve featuring soft seat and floating ball design for operations up to 10,000 PSI and depths down to 3050m. Designed and tested to API 17D PSL 3 (including API 6A PR2F) for safe and reliable performance in subsea applications.

Subsea Ball valve, 2-Way, Soft Seat | #S2BS8E10PK6B-H
Parker's 2-way subsea ball valve featuring soft seat and floating ball design for operations up to 10,000 PSI and depths down to 3050m. Designed and tested to API 17D PSL 3 (including API 6A PR2F) for safe and reliable performance in subsea applications.Parker's soft seated quarter turn ball valve for flow isolation, designed specifically to deliver smooth, low-torque performance in subsea applications. Utilising the same design technology as the standard Parker's Hi-Pro series ball valve, the subsea design incorporates the necessary design alterations to provide a reliable externally pressurized valve for the subsea industry.

Featuring PEEK self-relieving seat and PTFE packing, this subsea ball valve design incorporates additional o-ring seals, which prevent the ingress of sea water into the valve which would adversely affect the operation of the valve as well as contaminate the process liquid.The bi-directional valves are available in a range of corrosion-resistant alloys and are suitable for equipment located at depths down to 3,050m. The valves are designed to facilitate operation either manually or by a Remotely Operated Vehicle (ROV).

Parker's subsea ball valves have been designed to meet or exceed the rigorous qualification test requirements of API 17D PSL 3. The structural integrity and performance have been confirmed by Lloyds inspectors witnessing the API 17D valve design validation protocol. This was carried out on the base 316SS model and included the API 6A PR2F PSL3 bi-directional testing protocol as well as the API 17D Hyperbaric test protocol.


Markets:
- Upstream Oil & Gas (Liquid media)

Features/Benefits:
- Two-piece, floating ball style, side-entry construction
- Bi-directional liquid flow
- PEEK seats offer excellent resistance to chemicals, heat, and wear/abrasion
- Un-obstructed 10mm flow path
- Low friction, pressure assisted PTFE shaft seal increases cycle life and reduces operating torque
- Additional seals engineered to prevent water and silt ingress to any threaded or rotating parts
- Designed to accept multiple types of tube and pipe end connections
- Available in a variety of corrosion-resistant materials
- Designed and tested to API 17D/API 6A standards

Applications (liquid media):
- Subsea Hydraulic Manifolds
- Subsea Control Umbilicals
- Subsea Wellheads and Control Packages
- Chemical injection
- DBB, bleed, vents, test lines.



- New Parker Subsea Small-Bore Valves deliver leak-free, long-term performance in oil and gas exploration and production



Part

Bore Diameter (mm)

Additional Options

Options

Connection Size

Connection Type

Seat Material

Body Material

S2BS8E10PK6B-H

10

N/A

Handle

3/8"

Butt Weld

PEEK

Duplex Stainless Steel

S2BS8E10PK6B-HN

10

NACE certification

Handle

3/8"

Butt Weld

PEEK

Duplex Stainless Steel

S2BS8E10PK6B-P

10

N/A

ROV Low Torque Paddle

3/8"

Butt Weld

PEEK

Duplex Stainless Steel

S2BS8E10PK6B-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

Butt Weld

PEEK

Duplex Stainless Steel

S2BS8E10PK6N-H

10

N/A

Handle

3/8"

NPT

PEEK

Duplex Stainless Steel

S2BS8E10PK6N-HN

10

NACE certification

Handle

3/8"

NPT

PEEK

Duplex Stainless Steel

S2BS8E10PK6N-P

10

N/A

ROV Low Torque Paddle

3/8"

NPT

PEEK

Duplex Stainless Steel

S2BS8E10PK6N-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

NPT

PEEK

Duplex Stainless Steel

S2BS8E10PK8B-H

10

N/A

Handle

1/2"

Butt Weld

PEEK

Duplex Stainless Steel

S2BS8E10PK8B-HN

10

NACE certification

Handle

1/2"

Butt Weld

PEEK

Duplex Stainless Steel

S2BS8E10PK8B-P

10

N/A

ROV Low Torque Paddle

1/2"

Butt Weld

PEEK

Duplex Stainless Steel

S2BS8E10PK8B-PN

10

NACE certification

ROV Low Torque Paddle

1/2"

Butt Weld

PEEK

Duplex Stainless Steel

S2BS8E10PK8N-H

10

N/A

Handle

1/2"

NPT

PEEK

Duplex Stainless Steel

S2BS8E10PK8N-HN

10

NACE certification

Handle

1/2"

NPT

PEEK

Duplex Stainless Steel

S2BS8E10PK8N-P

10

N/A

ROV Low Torque Paddle

1/2"

NPT

PEEK

Duplex Stainless Steel

S2BS8E10PK8N-PN

10

NACE certification

ROV Low Torque Paddle

1/2"

NPT

PEEK

Duplex Stainless Steel

S2BS8E10PKM12-H

10

N/A

Handle

3/4"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM12-HN

10

NACE certification

Handle

3/4"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM12-P

10

N/A

ROV Low Torque Paddle

3/4"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM12-PN

10

NACE certification

ROV Low Torque Paddle

3/4"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM6-H

10

N/A

Handle

3/8"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM6-HN

10

NACE certification

Handle

3/8"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM6-P

10

N/A

ROV Low Torque Paddle

3/8"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM6-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM9-H

10

N/A

Handle

9/16"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM9-HN

10

NACE certification

Handle

9/16"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM9-P

10

N/A

ROV Low Torque Paddle

9/16"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8E10PKM9-PN

10

NACE certification

ROV Low Torque Paddle

9/16"

Cone and Thread

PEEK

Duplex Stainless Steel

S2BS8F10PK6B-H

10

N/A

Handle

3/8"

Butt Weld

PEEK

Super Duplex

S2BS8F10PK6B-HN

10

NACE certification

Handle

3/8"

Butt Weld

PEEK

Super Duplex

S2BS8F10PK6B-P

10

N/A

ROV Low Torque Paddle

3/8"

Butt Weld

PEEK

Super Duplex

S2BS8F10PK6B-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

Butt Weld

PEEK

Super Duplex

S2BS8F10PK6N-H

10

N/A

Handle

3/8"

NPT

PEEK

Super Duplex

S2BS8F10PK6N-HN

10

NACE certification

Handle

3/8"

NPT

PEEK

Super Duplex

S2BS8F10PK6N-P

10

N/A

ROV Low Torque Paddle

3/8"

NPT

PEEK

Super Duplex

S2BS8F10PK6N-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

NPT

PEEK

Super Duplex

S2BS8F10PK8B-H

10

N/A

Handle

1/2"

Butt Weld

PEEK

Super Duplex

S2BS8F10PK8B-HN

10

NACE certification

Handle

1/2"

Butt Weld

PEEK

Super Duplex

S2BS8F10PK8B-P

10

N/A

ROV Low Torque Paddle

1/2"

Butt Weld

PEEK

Super Duplex

S2BS8F10PK8B-PN

10

NACE certification

ROV Low Torque Paddle

1/2"

Butt Weld

PEEK

Super Duplex

S2BS8F10PK8N-H

10

N/A

Handle

1/2"

NPT

PEEK

Super Duplex

S2BS8F10PK8N-HN

10

NACE certification

Handle

1/2"

NPT

PEEK

Super Duplex

S2BS8F10PK8N-P

10

N/A

ROV Low Torque Paddle

1/2"

NPT

PEEK

Super Duplex

S2BS8F10PK8N-PN

10

NACE certification

ROV Low Torque Paddle

1/2"

NPT

PEEK

Super Duplex

S2BS8F10PKM12-H

10

N/A

Handle

3/4"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM12-HN

10

NACE certification

Handle

3/4"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM12-P

10

N/A

ROV Low Torque Paddle

3/4"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM12-PN

10

NACE certification

ROV Low Torque Paddle

3/4"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM6-H

10

N/A

Handle

3/8"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM6-HN

10

NACE certification

Handle

3/8"

Cone and Thread

PEEK

Super Duplex

-

Part

Bore Diameter (mm)

Additional Options

Options

Connection Size

Connection Type

Seat Material

Body Material

S2BS8F10PKM6-P

10

N/A

ROV Low Torque Paddle

3/8"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM6-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM9-H

10

N/A

Handle

9/16"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM9-HN

10

NACE certification

Handle

9/16"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM9-P

10

N/A

ROV Low Torque Paddle

9/16"

Cone and Thread

PEEK

Super Duplex

S2BS8F10PKM9-PN

10

NACE certification

ROV Low Torque Paddle

9/16"

Cone and Thread

PEEK

Super Duplex

S2BS8M10PK6B-H

10

N/A

Handle

3/8"

Butt Weld

PEEK

Inconel 625

S2BS8M10PK6B-HN

10

NACE certification

Handle

3/8"

Butt Weld

PEEK

Inconel 625

S2BS8M10PK6B-P

10

N/A

ROV Low Torque Paddle

3/8"

Butt Weld

PEEK

Inconel 625

S2BS8M10PK6B-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

Butt Weld

PEEK

Inconel 625

S2BS8M10PK6N-H

10

N/A

Handle

3/8"

NPT

PEEK

Inconel 625

S2BS8M10PK6N-HN

10

NACE certification

Handle

3/8"

NPT

PEEK

Inconel 625

S2BS8M10PK6N-P

10

N/A

ROV Low Torque Paddle

3/8"

NPT

PEEK

Inconel 625

S2BS8M10PK6N-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

NPT

PEEK

Inconel 625

S2BS8M10PK8B-H

10

N/A

Handle

1/2"

Butt Weld

PEEK

Inconel 625

S2BS8M10PK8B-HN

10

NACE certification

Handle

1/2"

Butt Weld

PEEK

Inconel 625

S2BS8M10PK8B-P

10

N/A

ROV Low Torque Paddle

1/2"

Butt Weld

PEEK

Inconel 625

S2BS8M10PK8B-PN

10

NACE certification

ROV Low Torque Paddle

1/2"

Butt Weld

PEEK

Inconel 625

S2BS8M10PK8N-H

10

N/A

Handle

1/2"

NPT

PEEK

Inconel 625

S2BS8M10PK8N-HN

10

NACE certification

Handle

1/2"

NPT

PEEK

Inconel 625

S2BS8M10PK8N-P

10

N/A

ROV Low Torque Paddle

1/2"

NPT

PEEK

Inconel 625

S2BS8M10PK8N-PN

10

NACE certification

ROV Low Torque Paddle

1/2"

NPT

PEEK

Inconel 625

S2BS8M10PKM12-H

10

N/A

Handle

3/4"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM12-HN

10

NACE certification

Handle

3/4"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM12-P

10

N/A

ROV Low Torque Paddle

3/4"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM12-PN

10

NACE certification

ROV Low Torque Paddle

3/4"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM6-H

10

N/A

Handle

3/8"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM6-HN

10

NACE certification

Handle

3/8"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM6-P

10

N/A

ROV Low Torque Paddle

3/8"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM6-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM9-H

10

N/A

Handle

9/16"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM9-HN

10

NACE certification

Handle

9/16"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM9-P

10

N/A

ROV Low Torque Paddle

9/16"

Cone and Thread

PEEK

Inconel 625

S2BS8M10PKM9-PN

10

NACE certification

ROV Low Torque Paddle

9/16"

Cone and Thread

PEEK

Inconel 625

S2BS8S10PK6B-H

10

N/A

Handle

3/8"

Butt Weld

PEEK

316 Stainless Steel

S2BS8S10PK6B-HN

10

NACE certification

Handle

3/8"

Butt Weld

PEEK

316 Stainless Steel

S2BS8S10PK6B-P

10

N/A

ROV Low Torque Paddle

3/8"

Butt Weld

PEEK

316 Stainless Steel

S2BS8S10PK6B-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

Butt Weld

PEEK

316 Stainless Steel

S2BS8S10PK6N-H

10

N/A

Handle

3/8"

NPT

PEEK

316 Stainless Steel

S2BS8S10PK6N-HN

10

NACE certification

Handle

3/8"

NPT

PEEK

316 Stainless Steel

S2BS8S10PK6N-P

10

N/A

ROV Low Torque Paddle

3/8"

NPT

PEEK

316 Stainless Steel

S2BS8S10PK6N-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

NPT

PEEK

316 Stainless Steel

S2BS8S10PK8B-H

10

N/A

Handle

1/2"

Butt Weld

PEEK

316 Stainless Steel

S2BS8S10PK8B-HN

10

NACE certification

Handle

1/2"

Butt Weld

PEEK

316 Stainless Steel

S2BS8S10PK8B-P

10

N/A

ROV Low Torque Paddle

1/2"

Butt Weld

PEEK

316 Stainless Steel

S2BS8S10PK8B-PN

10

NACE certification

ROV Low Torque Paddle

1/2"

Butt Weld

PEEK

316 Stainless Steel

S2BS8S10PK8N-H

10

N/A

Handle

1/2"

NPT

PEEK

316 Stainless Steel

S2BS8S10PK8N-HN

10

NACE certification

Handle

1/2"

NPT

PEEK

316 Stainless Steel

S2BS8S10PK8N-P

10

N/A

ROV Low Torque Paddle

1/2"

NPT

PEEK

316 Stainless Steel

S2BS8S10PK8N-PN

10

NACE certification

ROV Low Torque Paddle

1/2"

NPT

PEEK

316 Stainless Steel

-

Part

Bore Diameter (mm)

Additional Options

Options

Connection Size

Connection Type

Seat Material

Body Material

S2BS8S10PKM12-H

10

N/A

Handle

3/4"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM12-HN

10

NACE certification

Handle

3/4"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM12-P

10

N/A

ROV Low Torque Paddle

3/4"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM12-PN

10

NACE certification

ROV Low Torque Paddle

3/4"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM6-H

10

N/A

Handle

3/8"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM6-HN

10

NACE certification

Handle

3/8"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM6-P

10

N/A

ROV Low Torque Paddle

3/8"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM6-PN

10

NACE certification

ROV Low Torque Paddle

3/8"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM9-H

10

N/A

Handle

9/16"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM9-HN

10

NACE certification

Handle

9/16"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM9-P

10

N/A

ROV Low Torque Paddle

9/16"

Cone and Thread

PEEK

316 Stainless Steel

S2BS8S10PKM9-PN

10

NACE certification

ROV Low Torque Paddle

9/16"

Cone and Thread

PEEK

316 Stainless Steel


Products
- Aerospace Systems and Technologies
- Air Preparation (FRL) and Dryers
- Cylinders and Actuators
- EMI Shielding
- Filters, Separators and Purifiers
- Fittings and Quick Couplings
- Gas Generators
- Hose, Piping, Tubing and T-Slot Framing
- Medical and Dental Equipment
- Motors, Drives and Controllers
- Power Take Offs and Drive Systems
- Pumps
- Refrigeration and Air Conditioning
- Regulators, Monitoring, Sensors and Flow Control
- Seals and O-Rings
- Thermal and Power Management
- Valves
Parker Hannifin





美国DMK Engineering Solutions公司
信德迈科技(北京)有限公司 CNMEC Technology


E-mail:sales@cnmec.biz fcg.cnmec@parkerdistribution.com.cn
地址:北京市朝阳区望京街10号望京SOHO塔1C座2115室
邮编:100102
电话:010-8428 2935, 8428 9077, 8428 3983
手机:139 101 22694
Http://www.cnmec.biz
传真:010-8428 8762


京ICP备08000876号-1
京公网安备 11010502019740
Since 2007 Strong Distribution & Powerful Partnerships
