Ashcroft 1005 Series Pressure Gauge
This series of pressure gauges are available in 1 1/2" to 3 1/2" dials. This gauge has a black steel case, polycarbonate window for easy visability and is perfect for compressors, filter regulators, pumps, beverage dispensing equipment, or similar applications.
|
 |
Ashcroft 1001T Commercial Panel Gauge
This pressure gauge is available in 1 1/2" to 3 1/2" dial sizes. This gauge is perfect for panel mounting applications and has a very attractive design. It has a 1/4 turn polycarbonate window for better visability and removal if necessary. This gauge uses a U-Clamp design to mount to the panel. A front flange option is available for 2" and 2 1/2" dial sizes.
|
 |
Ashcroft 1008A/AL Stainless Steel Case Gauge
The 1008A/AL series is available in 2 1/2" or 4" dial sizes. The internal materials are a brass and bronze tube design and has a stainless steel case. This gauge can be liquid filled or dry and is great in adverse environment conditions.
|
 |
Ashcroft 3005 Commercial Hydraulic Gauge
This gauge is only available in 2 1/2" dial size. It has an ABS case and can be liquid filled or dry. This pressure gauge has superior performance in applications where vibration, pulsation, or mechanical shock and pressure spikes can happen.
|
 |
Ashcroft 1009, 1010, 1017, & 1220 Hydraulic Gauges
This series is available in 4 1/2", 6", 8 1/2", and 12" dial sizes. Can come in stainless steel, aluminum, or phenolic cases. These gauges are supplied with a slotted link movement to avoid gear wear as well as throttle devices. 1,000psi to 20,000 psi ranges are available.
|
 |
Ashcroft 2089 Digital Test Gauge
This digital gauge has an unmatched accuracy of +0.05% accuracy which makes it perfect for testing applications. It has a rugged portable design with 12 units of measure and 7 languages. It has a 5 digit LCD display for easy reading and has a % of reading bar graph scale. |
 |
Ashcroft D1005PS General Purpose Digital Gauge
The D0015PS offers 0.5% accuracy and has multiple units of measure for ease of use. The welded material is Stainless Steel which makes it suitable for multiple applications. It has a max pressure indicator, ranges from vacuum to 19,999 psi, and has a 2 1/2" dial.
|
 |
Ashcroft 2074 and 2174 Industrial Digital Gauges
This is a multi-functional digital gauge with options like 4/20ma output or SPDT switches. This gauge comes in 3" dial or 4 1/2" process style dial and case. Ranges are available from 30"Hg Vac to 20,000 psi and can read in 10 different units of measure. +0.25% accuracy is standard along with a backlight, min/max peak hold and zero reset.
|
 |
Ashcroft 1133 Differential Pressure Gauge
This gauge uses a large convoluted diaphragm actuator which allows it to sense low inches of water differentials while insuring no migration of media. The body materials can come in Aluminum, Brass and Stainless Steel with Buna, Viton, or EPDM Seals.
|
 |
Ashcroft 1127/1128 Differential Pressure Gauge
This gauge comes in 4" dial or 6" dial sizes and ranges from 10 psi to 1,000 psi. 1127 model with 0 at the 7:00 position and the 1128 model has 0 at the 12:00 position. The 1127/1128 series comes with a back flange case for easy wall mounting and also has 316 SS wetted parts.
|
 |
Ashcroft 1130 Differential Pressure Gauge
This piston actuator gauge can come in dial sizes 2" all the way to 6". This gauge is recommended for high differential and high static pressures up to 6,000 psi. The body materials can come in Aluminum, Brass and Stainless Steel with Buna, Viton, or EPDM Seals.
|
 |
Ashcroft 1131 Differential Pressure Gauge
This differential gauge has a rolling diaphragm actuator and a stainless steel case. it can come in sizes 2 1/2" through 6". This gauge is great where migration of the process media is not permissible. The body materials can come in Aluminum, Brass and Stainless Steel with Buna, Viton, or EPDM Seals.
|
 |
Ashcroft 1132 Differential Pressure Gauge
This differential gauge has a small convoluted diaphragm actuator and a stainless steel case. it can come in sizes 2 1/2" through 6". This gauge is great where migration of the process media is not permissible. It is recommended for lower differential and high static pressures. The body materials can come in Aluminum, Brass and Stainless Steel with Buna, Viton, or EPDM Seals.
|
 |
Ashcroft 23DDG MiniGauge Pressure Gauge
The MiniGauge comes in a 23mm (.906") size dial and an ABS case with an acrylic window. The available ranges are 60psi to 300psi and it uses Direct Drive technology for excellent shock resistance. Because it uses a spiral tube to transmit motion directly to the pointer, no gear or movement parts are needed.
|
 |
Ashcroft 1007P, XOR Refrigeration Pressure Gauge
This pressure gauge comes in 2 1/2" dial and offers 4 refrigeration scales (R12, R22, R502, 134A). The connection time is 1/8" npt and can come in blue or red casing.
|
 |
Ashcroft 40DDG Pressure Gauge
The 40DDG series comes in a 1 1/2" dial or 2" dial and an ABS case with an acrylic window. The available ranges are 60psi to 400psi and it uses Direct Drive technology for excellent shock resistance. Because it uses a spiral tube to transmit motion directly to the pointer, no gear or movement parts are needed.
|
 |
Ashcroft 1105M Refrigerant Ammonia Gauge
This pressure gauge is available in 2 1/2" or 3 1/2" dials, and can come in black painted steel or stainless clad aluminum casing. The available pressure ranges are 30inHg/150psi or 30inHg/300psi with equivalent ammonia temperature scales.
|
 |
Ashcroft 1005P XUL Fire/Sprinkler Service Gauge
The Ashcroft sprinkler gauge comes in a 3 1/2" dial and a corrosion-resistant ABS Case. It has a heat-resistant polycarbonate push-in window and can come UL listed and Factory Mutual approved if desired.
|
 |
Ashcroft 1279 Duragauge Series Process Gauge
Available in 4 1/2" dial and has a phenolic black case. Internal material options available are Brass/Bronze, 316 Stainless Steel and Steel Socket, All Stainless Steel, and K Monel. Has a micrometer adjustable pointer and is available in compound ranges, vacuum, and 15 to 30,000 psi.
|
 |
Ashcroft 1377 Duragauge Series Process Gauge
The 1377 series is available in 4 1/2", 6", and 8 1/2" dial sizes and has a flush mounting aluminum case great for panel mounting. Internal material options available are Brass/Bronze, 316 Stainless Steel and Steel Socket, All Stainless Steel, and K Monel. Has a micrometer adjustable pointer and is available in compound ranges, vacuum, and 15 to 30,000 psi.
|
 |
Ashcroft 1379 Duragauge Series Process Gauge
The 1379 series is available in 4 1/2", 6", and 8 1/2" dial sizes and has a rugged solid-front aluminum case that is weatherproof and hermetically sealed. Internal material options available are Brass/Bronze, 316 Stainless Steel and Steel Socket, All Stainless Steel, and K Monel. Has a micrometer adjustable pointer and is available in compound ranges, vacuum, and 15 to 100,000 psi. |
 |
Ashcroft 1032 Sanitary Gauge
This gauge can come in 2 1/2", 3 1/2", and 4 1/2" dial sizes and is specifically designed specifically to meet the needs of the sanitary market. It can come in dry or liquid filled. The 1032 series is all stainless steel and can come in 1 1/2" or 2" tri-clamp connections.
|
 |
Ashcroft X1032 Xmitr Transmitter Sanitary Gauge
The X1032 Xmitr is a unique gauge to Ashcroft. This sanitary gauge gives an analog reading as well as a 4/20ma output. The dial size is 2 1/2" dial and can come in 1 1/2" or 2" tri-clamp connections. This instrument meets 3A sanitary standards and ranges compound to 1,000 psi. |
 |
Ashcroft 1036 and 1037 Sanitary Gauge
This gauge comes in 3 1/2" dial size and tube fittings of 1/2" through 2" tri-clamp. It is all-welded stainless steel and can be dry or liquid filled. This gauge is perfect for food industries and complies to 3A standards.
|
 |
Ashcroft 1008/1008S Series Pressure Gauge
This series gauge is available in 1 1/2" dial to 4" dial. It has an all stainless steel construction and can come dry or liquid filled. These gauges are great where there are space limitations and process or atmospheric corrosion is present.
|
 |
Ashcroft 1009 Series Duralife Pressure Gauge
This Grade 1A gauge is available in 2 1/2" or 3 1/2" dial. It has an all stainless steel design and can be converted to panel mounting if necessary. The Duralife gauge has a 5 year limited warranty and will give outstanding performance in the field.
|
 |
Ashcroft 1109 Service Gauge
This is a very unique gauge to Ashcroft. It has a solid front case design with full blowout back and comes in a 4 1/2" dial size. The case and wetted materials are stainless steel (inconel 718 for high pressures) and is available at 15 psi all the way up to 100,000 psi.
|
 |
Ashcroft 8008S pressure gauge
8008S 压力表
Ashcroft 8008S 以小巧、经济的包装提供更大规格的先进功能，适用于需要在恶劣环境下使用全不锈钢仪器的应用。激光焊接润湿 316L 不锈钢部件可确保系统在腐蚀??性介质中的完整性。还提供坚固的前壳选项，以提高操作员的安全性以及多种安装选择，以节省空间并简化安装。The Ashcroft 8008S delivers the advanced features of a larger gauge in a small, economical package for applications requiring an all stainless steel instrument for harsh environments. Laser welded wetted 316L stainless steel components ensure system integrity for corrosive medias. A solid front case option is also available to enhance operator safety along with numerous mounting selections to save space and ease installation. |
